S110
The highly productive machine for small bores.
Basic Data
The S122 is a CNC production internal cylindrical grinding machine for small to medium-sized workpieces in small and large-scale production. The machine has a swing diameter of 220mm (8.6″).
The CNC production internal cylindrical grinding Machine can machine workpieces up to a length of 120mm (4.7″). The grinding length is maximum 110mm (4.3″). Up to three grinding spindles can be used in a parallel arrangement. One of these can take an external grinding wheel. The basis for the machine’s legendary precision is the Granitan® machine bed and the StuderGuide® guide system for the X- and Z-axis.
Linear Axes
Max. Travel Speed X
Max. Travel Z
Max. Travel Speed Z
350 mm
20’000 mm/min
350 mm
20’000 mm/min
SPindle Drive
Max. Number Of Revolutions
Max. Grinding Wheel Diameter
Max. Grinding Wheel Width
15 kW
120’000 /min
150 mm
20 mm
Swiveling Axes
Workpiece Data
Workpiece Length
Workpiece Diameter
Max. Workpiece Weight
Center Height
120 mm
70 mm
3kg
110 mm
Linear Axes
Max. Travel X: 350mm
Max. Travel Speed X: 20’000 mm/min
Max. Travel Z: 350mm
Max. Travel Speed Z: 20’000 mm/min
SPindle Drive
Max. Spindle Power: 15 KW
Max. Number Of Revolutions: 120’000/min
Max. Grinding Wheel Dm: 150mm
Max. Grinding Wheel Width: 20mm
Swiveling Axes
Workpiece Data
Workpiece Length: 120mm
Workpiece Diameter: 70mm
Max. Workpiece Weight: 3kg
Center Height: 110mm
